Servo Motor Precision Injection Molding Machine , High Pressure Injection Molding Equipment

Large Image : Servo Motor Precision Injection Molding Machine , High Pressure Injection Molding Equipment

Product Details:

Place of Origin:	Zhejiang China
Brand Name:	HAICHEN
Certification:	ISO9001:2000, CE
Model Number:	HCC350

Payment & Shipping Terms:

Minimum Order Quantity:	1SET
Packaging Details:	Wooden Pallet
Delivery Time:	20Days
Payment Terms:	L/C, T/T
Supply Ability:	160-220SETS/One Month

Contact Now

Detailed Product Description

Clamping Force::	350tons	Style::	Horizontal
Material::	PE, Plastic, A.B.S	Feature::	Energy Saving
Highlight:	automatic cold chamber die casting machine

HCC350 Precision Injection molding Equipment With EISSO Transducer

Condition:	New	Type:	plastic injection molding machine	Style:	Horizontal
Brand Name:	HAICHEN	Model Number:	HCC350	Place of Origin:	Zhejiang, China (Mainland)
Plastic Type:	Thermoplastic	Automatic:	Yes	Injection Weight:	1159(g)

Quick Detail:
HCC350 adopts servo energy-saving controlling , through proportional control of pressure flow achieve rapid multi-level pressure, speed switching, the system configuration is reasonable, stable and reliable, easy to operate, easy to maintain and other characteristics.

HYDRAULIC SYSTEM

-The double proportional compund value control system pressure and flow, high sensitivity and stability
-Adopt the imported pump, low noise, long lifetime,stabke performance
-The optional world-class servo hydraulic system, lower noise, energy-saving
-The precise feedback control of servo system to the pressure and flow, with higher sensitivity and more accurate repeatability precision
-High performance hydraulic valve, less failure, fast switch, convenient maintenance
-Low pressure mould protect system, which is more suitable for the precision mould
-Greese and lubricating oil in dependent lubrication system can lubricate everywhere in the best situation

Hydraulic Unit:

Valve's manufacture use Taiwan technology; Hydraulic circuit's design meet international security standard; Automatic read the oil temperature; Non-welding tubing, reach long reliability and convenient service; Apply internationally known hydraulic comp-onents.

.INJECTION PREPLASTICATION SEAT WITH OIL COPPER SLEEVE
The preplastication seat reciprocates once in every injection motion. Normal non-automatic lubrication in injection unit can't offer lubrication support to this important motion. Thus, we use oil copper sleeve to make sure that injection reciprocates well. Even without lubricating oil support, it can also slide excellently.
Considering cost, however, some materials without oil always cause hamful effect to injection accuracy after a period of time.

Specifications :

INTERNATION CLASS NO		HCC350
		A	B
INJECTION UNIT
Screw diameter	mm	60	65	70
Shot volume(theoretical)	cm3	935	1098	1274
Injiection weight(ps)	g	851	1000	1159
Injection Rate	g/s	267	314	364
Screw pressure	Mpa	213	182	156
Screw speed	rpm	225
CLAMPING UNIT
Clamping force	kN	3500
Open stroke	mm	630
Space between tie bars(W×H)	mm	670*670
Max.Mold height	mm	670
Min.Mold height	mm	270
Ejector stroke	mm	170
Ejector force	kN	90
OTHERS
Pump motor power	kW	35
Heating power	kW	19.65
Machine dimension(L×W×H)	m	6.0×1.70×2.3
Oiltank cubage	L	800
Machine weight	t	13.5
